flink-cdc同步mysql到doris的一個常見的類型錯誤處理


一、varchar類型

日誌報錯如下：

java.lang.IllegalArgumentException: Variable character string length must be between 1 and 2147483647 (both inclusive).
	at org.apache.flink.cdc.common.types.VarCharType.<init>(VarCharType.java:52) ~[?:?]
	at org.apache.flink.cdc.common.types.VarCharType.<init>(VarCharType.java:60) ~[?:?]
	at org.apache.flink.cdc.common.types.DataTypes.VARCHAR(DataTypes.java:150) ~[?:?]
	at org.apache.flink.cdc.connectors.mysql.utils.MySqlTypeUtils.convertFromColumn(MySqlTypeUtils.java:207) ~[?:?]
	at org.apache.flink.cdc.connectors.mysql.utils.MySqlTypeUtils.fromDbzColumn(MySqlTypeUtils.java:113) ~[?:?]
	at org.apache.flink.cdc.connectors.mysql.source.reader.MySqlPipelineRecordEmitter.parseDDL(MySqlPipelineRecordEmitter.java:204) ~[?:?]
	at org.apache.flink.cdc.connectors.mysql.source.reader.MySqlPipelineRecordEmitter.getSchema(MySqlPipelineRecordEmitter.java:136) ~[?:?]
	at org.apache.flink.cdc.connectors.mysql.source.reader.MySqlPipelineRecordEmitter.generateCreateTableEvent(MySqlPipelineRecordEmitter.java:242) ~[?:?]
	at org.apache.flink.cdc.connectors.mysql.source.reader.MySqlPipelineRecordEmitter.<init>(MySqlPipelineRecordEmitter.java:84) ~[?:?]
	at org.apache.flink.cdc.connectors.mysql.source.MySqlDataSource.lambda$getEventSourceProvider$22720ae2$1(MySqlDataSource.java:55) ~[?:?]
	at org.apache.flink.cdc.connectors.mysql.source.MySqlSource.createReader(MySqlSource.java:188) ~[?:?]
	at org.apache.flink.streaming.api.operators.SourceOperator.initReader(SourceOperator.java:316) ~[flink-dist-1.20.0.jar:1.20.0]
	at org.apache.flink.streaming.runtime.tasks.SourceOperatorStreamTask.init(SourceOperatorStreamTask.java:94) ~[flink-dist-1.20.0.jar:1.20.0]
	at org.apache.flink.streaming.runtime.tasks.StreamTask.restoreInternal(StreamTask.java:800) ~[flink-dist-1.20.0.jar:1.20.0]
	at org.apache.flink.streaming.runtime.tasks.StreamTask.restore(StreamTask.java:771) ~[flink-dist-1.20.0.jar:1.20.0]
	at org.apache.flink.runtime.taskmanager.Task.runWithSystemExitMonitoring(Task.java:970) ~[flink-dist-1.20.0.jar:1.20.0]
	at org.apache.flink.runtime.taskmanager.Task.restoreAndInvoke(Task.java:939) ~[flink-dist-1.20.0.jar:1.20.0]
	at org.apache.flink.runtime.taskmanager.Task.doRun(Task.java:763) ~[flink-dist-1.20.0.jar:1.20.0]
	at org.apache.flink.runtime.taskmanager.Task.run(Task.java:575) ~[flink-dist-1.20.0.jar:1.20.0]
	at java.lang.Thread.run(Thread.java:842) ~[?:?]
flink-cdc同步mysql到doris，報這個錯

原因就是VarCharType的長度為沒有在（1-2147483647 ）之間。Variable character string length must be between 1 and 2147483647 ，varchar一般都要填寫長度，可能有些給寫成了0,在mysql中沒有問題呢，在其他數據庫就會由問題。

可以執行下面的SQL語句查看具體情況

SELECT
    TABLE_SCHEMA AS '數據庫名',
    TABLE_NAME AS '表名',
    COLUMN_NAME AS '字段名',
    DATA_TYPE AS '數據類型',
    CHARACTER_MAXIMUM_LENGTH AS '最大長度'
FROM INFORMATION_SCHEMA.COLUMNS
WHERE DATA_TYPE = 'varchar'
AND CHARACTER_MAXIMUM_LENGTH = 0
ORDER BY TABLE_SCHEMA, TABLE_NAME;
SELECT
    TABLE_SCHEMA AS '數據庫名',
    TABLE_NAME AS '表名',
    COLUMN_NAME AS '字段名',
    DATA_TYPE AS '數據類型',
    CHARACTER_MAXIMUM_LENGTH AS '最大長度',
    COLUMN_TYPE AS '定義的類型'
FROM INFORMATION_SCHEMA.COLUMNS
WHERE DATA_TYPE = 'varchar'
AND CHARACTER_MAXIMUM_LENGTH = 0
ORDER BY TABLE_SCHEMA, TABLE_NAME;

flink-cdc同步mysql到doris的一個常見的數據類型錯誤處理_apache

varchar(0)在mysql中沒有問題，在doris中就會出現問題。


二、int類型

int類型也有類似錯誤，因為創建數據庫不規範，還有很多int(255),像這樣的情況，mysql沒有問題，但是doris就會有問題。

SELECT
    TABLE_SCHEMA AS '數據庫名',
    TABLE_NAME AS '表名',
    COLUMN_NAME AS '字段名',
    DATA_TYPE AS '數據類型',
    CHARACTER_MAXIMUM_LENGTH AS '最大長度',
    COLUMN_TYPE AS '定義的類型'
FROM INFORMATION_SCHEMA.COLUMNS
WHERE DATA_TYPE = 'int'
AND TABLE_SCHEMA = 'twms'
AND COLUMN_TYPE = 'int(255)'
ORDER BY TABLE_SCHEMA, TABLE_NAME;

這個 COLUMN_TYPE = 'int(255)' 是我們這裏的問題，int類型大於21就算有問題了吧。你們可以去確認下。

flink-cdc同步mysql到doris的一個常見的數據類型錯誤處理_apache_02
